Onguard FG8800-1705 Addressable Field Node Four Channel Supervised Outputs

Onguard FG8800-1705 Addressable Field Node Four Channel Supervised Outputs

The FG8800-1705 is a heavy duty, 7.5 amps per channel, microprocessor based supervised output module (SOM). The node provides four independent appliance outputs to various devices. LED’s on each channel indicate the real time status of the relay output. Each channel has its own unique address and can be treated as an individual output for the system. Disabled or unused channels do not require an ELR. The choice to disable any channel is implemented through the program. The node and its field wiring are continuously supervised and interrogated through the control panel.

Onguard FG8800-1705 Addressable Field Node Four Channel Supervised Outputs

Onguard FG8800-1705 Addressable Field Node Four Channel Supervised Outputs

Node Notes:
  1. 4 mounting hole diameters, .170" (4.32MM).
  2. * For constraint areas, Allestec can remove end tabs allowing node to accommodate a 4-0 electrical junction box.
  3. Node maximum depth = .9" (22.86).
  4. Tolerances are +/- .005 (.127).
Adapter notes:
  1. Node can be rotated on the adapter 180° to accommodate terminal strip position.

Approvals

Specifications of the Onguard FG8800 System Supervised Output Node

Electrical

Node operating voltage:

18 - 30 VDC provided to the control panel

SOM current rating @ 24 VDC:

23mA quiescent, 108mA maximum

Relay output current sourcing:

7.5 amps per channel @ 24 VDC

Printed circuit board:

FR4 fiberglass UL rated 94V-0, 2 oz copper, SMOBC, MIL-PRF-55110F

RF sheilding:

Pending

Mechanical

Dimensions:

Refer to above drawing

Weight:

6.5 oz, 185g

Environment

Node operating ambient temperature:

0°F to 150°F
-17°C to 65°C
90% humidity non-condensing

Packaging and exposure:

NEMA 1


Node ordering part number:

FG8800-1705
